Here are 6 fully automatic electric double wire cable cutting cutter and stripping stripper machine for sell low manufacturer price in india
Model:- Yukti 277 High speed 4 square fully automatic electric wire Cable line cutting and stripping machine low price in india.
The cable wire cutting and stripping machine uses the latest 32-bit intelligent control system. This machine stores hundreds of pieces of information. English switching liquid crystal display. Fast efficiency high speed. Compatible with all features of 330 # wire cutting machine. Two wires can be processed simultaneously, saving labor and time and improving productivity. Mainly used for electronic wire, Teflon wire, silicone wire, glass fiber of cotton, isolated lines, coaxial, automatic cutting, stripping, semi stripping, multi-segment stripping, and twisting function once completed. Can right away transform wire specifications also dimensions it’s very economic. It's an automatic wire cable cutting and stripping machine. Features: 1. Buttons also process programs designed based on automatic CPU programming, simple and easy to operate. 2. Four-wheel driving work for wire feeding, changeable wire pressing force, and high wire feeding accuracy, no damage on wire also no press marks. 3. High-quality blades made in japan, the cut edges are burr-free, and wear-resistant also can be used for a longer time. 4. The pressing force of four-wire feeding wheels can be attuned which can help to process various sizes of wires better. 5. Equipped with the copper core stepper motor which is high precision, precise current control, low noise, low motor heating, and longer service life. 6. The smart control system, using the 32-bit cortex-m3 core processor, can store hundreds of parameter settings. Our company advantage: 1. We can provide professional technical support 365 days. 2. We are a government-audited iso-certified company in India. 3 we are R&D facility leading manufacture and import-export company. We have already added all details in the product catalog using the below button.
Technical Specifications.
Model:- Yukti 277. Weight:- 25kg. Dimension Mm:- 400*300*330. Catheter Diameter Mm:- 1.5 To 5.5. Cutting Length:- 1~99999mm. Middle Stripping:-15. Wire Core Diameter:-0.1~4. Cutting Tolerance:- 0.002L. Blade Material:- Imported High Speed Steel. Drive Mode:- Four Wheel Drive. Pressure Adjustment:- Yes. Pulse Equivalent:- 500 Error Free. Drive Motor:- 0.1mm Stepper Motor. Speed:- 3000~5000 Pcs/H. Function:- Automatic Feeding, Setback, Output Setting, Timing Power On Off. Stripping Length:- Thread Head 20mm, Thread Tail 15mm. Power:- Ac 220 50hz. Control:- LCD Display. Warranty:- 1 Year (Normal blade wear and tear is not covered by the warranty). Support:- Online. Shipping:- All India Free. Usage / Application:- for cutting and stripping wire cable.
Price:- 116000 ₹ + 18% GST 20,880 ₹ Total Payable:- 1,36,880 ₹.
Model:- Yukti 281 10 Square mm wire cutting and stripping machine manufacturer price in india.
We are a professional supplier of machines mainly processing various wires also cables. YUKTIRAJ is our brand also we have the R&D Department for upgrading our cable wire cutting and stripping machine. We provide professional technical support all days no break. Features: 1. fully automatic cutting also stripping, high performance. 2. Suitable for Teflon cables, PVC cables, Silicone cables, glass fiber cables, etc. 3. LCD touch screen dialog mode, simple operation, easy maintenance, stable performance, fast speed, beautiful appearance, and high precision. 4. Saving labor and time also rising productivity. 5. Widely used in wire processing in the electronics industry, automotive and electrical appliances, motorcycle parts industry, motors, lamps, toys, etc. we specialize in the production of wire also cable processing equipment, and wiring harness processing machines. We are dedicated to providing optimal solutions for cable precise processing and also an automatic machine for technology. We offer quick support 365 days. We have already added all details in the product catalog using the below button.
Technical Specifications.
Model:- Yukti 281. Weight:- 35kg. Dimension Mm:- 400*300*330. Catheter Diameter Mm:- 1.5 To 10mm. Cutting Length:- 1~99999mm. Middle Stripping:-15. Wire Core Diameter:-0.1~10. Cutting Tolerance:- 0.002L. Blade Material:- Imported High Speed Steel. Drive Mode:- Four Wheel Drive. Pressure Adjustment:- Yes. Pulse Equivalent:- 5mm Error Free. Drive Motor:- 0.1mm Stepper Motor. Speed:- 3000~5000 Pcs/H. Function:- Automatic Feeding, Setback, Output Setting, Timing Power On Off. Stripping Length:- Thread Head 20mm, Thread Tail 15mm. Power:- Ac 220 50hz. Control:- LCD Display. Warranty:- 1 Year (Normal blade wear and tear is not covered by the warranty). Support:- Online. Shipping:- All India Free. Usage / Application:- for cutting and stripping wire cable.
Price:- 130000 ₹ + 18% GST 23,400 ₹ Total Payable:- 1,53,400 ₹.
Model:- Yukti 278. 16 Square mm fully automatic computerized double wire cutting and stripping tools machine best price in india.
Its best 16 Square mm fully automatic wire cutting and stripping tools machine best price in india. Advantage: Peeling wire at both ends, half peeling, multiple peeling, full peeling, and cutting in the middle. The two wheels are driven at the same time, the gear is cut off, the knife cut is neat also the stripping quality is stable. no damage Low loss. Durable and abrasion-resistant. Simple and essay operation interface convenient. The wire is straighter and more precise, improving job quality also efficiency. New economical and high-speed work. core processor running, fast speed, and stable performance. Super Fast heat dissipation is also high-speed silent. stable performance and longer life. It's an automatic wire cable cutter and stripper machine. Our company benefit: YUKTIRAJ PVT LTD was established in 2019, It is a professional company occupied in new energy wire processing equipment, accuracy three-axis dispensing machines, soldering machines, screw machines, non-standard automation also other high-end automation products. We are located in Karanja city District washim state Maharashtra India, Mumbai with convenient transportation access. Dedicated to strict quality control also thoughtful customer service, our qualified staff members are always obtainable to discuss your requirements and also ensure full customer satisfaction. All products can be tested for needed certificates with your standard also request, We always adhere to the business viewpoint of Customer First, Service Foremost. We are already adding all details in the product catalog using the below button.
Technical Specifications.
Model:- Yukti 278. Weight:- 45kg. Dimension Mm:- 420*350*360. Catheter Diameter Mm:- 1.5 To 12. Cutting Length:- 1~99999mm. Middle Stripping:-15. Wire Core Diameter:-0.1~16. Cutting Tolerance:- 0.002L. Blade Material:- Imported High Speed Steel. Drive Mode:- Four Wheel Drive. Pressure Adjustment:- Yes. Pulse Equivalent:- 5mm Error Free. Drive Motor:- 0.1mm Stepper Motor. Speed:- 2000~4000 Pcs/H. Function:- Automatic Feeding, Setback, Output Setting, Timing Power On Off. Stripping Length:- Thread Head 25mm, Thread Tail 80mm. Power:- Ac 220 50hz. Control:- LCD Display. Warranty:- 1 Year (Normal Blade Wear And Tear Is Not Covered By The Warranty). Support:- Online. Shipping:- All India Free. Usage / Application:- for cutting and stripping wire cable.
Price:- 1,60,000 ₹ + 18% GST 28,800 ₹ Total Payable:- 1,88,800 ₹.
Model:- Yukti 279. 35 square mm automatic electric wire cable wire stripper cutter machine low manufacture price in india.
This machine is suitable for processing electronic wire, isolation wire, sheath wire, silicone wire, Teflon wire, multi-strand copper core wire, tube beating function, and eight-wheel speed drive the cutting wire area is 35 square mm or less. Model Yukti 279 is half stripping, full stripping, wire cable cutting, and multi-layer stripping function, specially designed for sheathed wire and coaxial wire. After it is turned on, a certain section of wire cable will be stripped separately according to the predetermined parameters. It can be twisted off when not needed. This machine used a motor to drive the tube, which has the quality of little noise, and constant operation. Its automatic cable cutting and stripping machine application of 32-bit ultra core processor, operation speed up to 72 m, also store hundreds of information to call at any time. Machine advantage: 1. Save more labor costs also boost the production rate. 2. High-efficiency more output 3. Super high-speed working whiteout failover rate. 4. Longer life simple to operate. 5. High power saving new generation machine. 6. Fully convenient adjustment. Yuktiraj Pvt Ltd was founded in 2019 and is a top supplier of wire processing, and cutting machines. We mostly focus on research also development, and production learning from japan Taiwan techniques and experience. Our main products include automatic wire cut strip crimp machine, auto cut strip also crimping machine. Quality and service are our cultures. We have already add all details in the product catalogue use the below button.
Technical Specifications.
Model:- Yukti 279. Weight:- 56kg. Dimension Mm:- 420*350*360. Catheter Diameter Mm:- 1.5 To 15. Cutting Length:- 1~99999mm. Middle Stripping:-15. Wire Core Diameter:-0.1~35. Cutting Tolerance:- 0.002L. Blade Material:- Imported High Speed Steel. Drive Mode:- Four Wheel Drive. Pressure Adjustment:- Yes. Pulse Equivalent:- 5mm Error Free. Drive Motor:- 0.1mm Stepper Motor. Speed:- 2000~4000 Pcs/H. Function:- Automatic Feeding, Setback, Output Setting, Timing Power On Off. Stripping Length:- Thread Head 30mm, Thread Tail 30mm. Power:- Ac 220 50hz. Control:- LCD Display. Warranty:- 1 Year (Normal Blade Wear And Tear Is Not Covered By The Warranty). Support:- Online. Shipping:- All India Free. Usage / Application:- for cutting and stripping wire cable.
Price:- 1,99,000 ₹ + 18% GST 35,820 ₹ Total Payable:- 2,34,820 ₹.
Model:- Yukti 280 70 Square mm
automatic double electric cable wire cutting and stripping machine low price in
india.
Model:- Yukti 280 Have a Control system 32-bit ultra core processor, with a 7-inch industrial touch screen, easy operation, and high constancy. Take on eight cable feed rollers with an outer thickness of 45 mm, the contact area between the roller and the cable is large, the wire feed is stable, and the length is accurate. The control structure is highly integrated to decrease the failure rate of the system. Able to with a large-capacity memory that can save a hundred groups of parameters at the same time, and convenient for operation. The space between the front and rear rollers is controlled by a motor that just inputs the wire diameter, which is easy to operate. The upper and lower rollers are adjusted synchronously, the center point of the blade is always the same, and there is no need to adjust the blade when dispensation large or small lines. The machine is all driven by electric motors, no compressed air is needed, and it is versatile. its Best 70 Square mm automatic cable cutting and stripping machine low price in india. We have already added all details in the product catalog using the below button.
Technical Specifications.
Model:- Yukti 280. Weight:- 80kg. Dimension Mm:- 700*640*480. Cutting and peeling range:- 0~100m. Wire Core Diameter:-6~70sqmm. Cutting Tolerance:- 0.002L. Blade Material:- Imported High Speed Steel. Feeding catheter:- 20mm. cutting tolerance:- 0.002mmL. Peeling minimum length:- 50mm. Drive Mode:- 12 Wheel Drive. Speed:- 1500~2500 Pcs/H. Function:- Automatic Feeding, Setback, Output Setting, Timing Power On Off. Stripping Length:- Thread Head 30mm, Thread Tail 30mm. Power:- Ac 220 50hz. Power consumption:-800w. Control:- LCD Display. Suitable wire:- multi strand copper wire, coaxial cable, sheathed wire etc. Warranty:- 1 Year (Normal Blade Wear And Tear Is Not Covered By The Warranty). Support:- Online. Shipping:- All India Free. Usage / Application:- for cutting and stripping wire cable.
Price:- 3,90,000 ₹ + 18% GST 70,200 ₹ Total Payable:- 4,60,200 ₹.
Model:- Yukti 31. 3F pneumatic electrical wire Peeling machine for AC/DC, power cord, sheath wire, computer cable electronic wire stripper.
Model yukti-31 have a Pneumatic control, improved aircraft design, advanced and suitable diameter AWG 18 to 32. Double moving cylinder, free of spring breakage. The 2 cylinders of oil and gas self supply provide standard oil supply to cylinder, reduce internal wear and extend service life. Unique slide seat, stable reciprocating stroke accurate stripping. Pneumatic control, light and agile, simple easy to operate. Debug structure, adjust the thickness of the line of sight. It is suitable for the processing of large and small wires and long and short wires. Such as AC or DC, power cord, computer wire, electronic wire, sheath wire, multi-core wire, cable, flat line, etc. Its best world class full high speed 3F pneumatic electrical wire Peeling machine for AC DC power cord sheath wire computer cable electronic wire stripper machine low price high quality in india.We already add all details in product catalogue use below button.
Technical
specifications.
Power
supply:- AC 220/110V. Air pressure:- 3-7KG. Stripping diameter:- 32#-16#. Stripping length:- 25mm. Dimension:-
330*190*270mm. Weight:- 12KG.
Warranty:- 1 Year. Sale support:- online. Usage / Application:- for cutting
and stripping wire cable.
Price:- 60000 ₹+ 18% Gst 10,800 ₹ Total Payable:- 70,800 ₹.
